Bars Emitter 1500W
Bars Emitter 1500W
Technical Specifications
Technical Specifications
| Parameter | Unit | Value |
| Optical | ||
| Center Wavelength λ | nm | 808 |
| Wavelength Tolerance | nm | ±15 |
| Output Power per bar | W | 100 |
| Spectral Width FWHM | nm | ≤5 |
| Spectral Width FW90%E | nm | ≤8 |
| Fast Axis Divergence( FWHM) | degree | 10 |
| Slow Axis Divergence (FWHM) | degree | 12 |
| Polarization Mode | - | TE |
| Wavelength Temp. Coefficient | nm/°C | ~0.28 |
| Electrical Parameters | ||
| Operating Current | A | ≤110 |
| Threshold Current | A | ≤30 |
| Operating Voltage | V | ≤2 |
| Slope Efficiency | W/A | ≥1.1 |
| Power Conversion Efficiency | % | ≥48 |
| Pulse Width | ms | ≤100 |
| Duty Cycle | % | ≤20 |
| Thermal Parameters | ||
| Operating Temperature | °C | 22~28 |
| Coolant | - | Distilled water |
| Flow Rate per bar | L/min | 2~4 |
For Details, please contact us freely.
